IMP-02
I3
Wide profile traction tire designed for high flotation and minimal soil compaction
Features
■Reinforced undertread and shoulder protects from cuts and stubble damage
■Cut resistant tread compound extends tire life
■Wide, aggressive tread design provides excellent traction and stability
■Large footprint reduces ground pressure and soil disturbance
■Low rolling resistance
Applications
Wide profile traction tire designed for high flotation and minimal soil compaction
Features
■Reinforced undertread and shoulder protects from cuts and stubble damage
■Cut resistant tread compound extends tire life
■Wide, aggressive tread design provides excellent traction and stability
■Large footprint reduces ground pressure and soil disturbance
■Low rolling resistance
Applications
Description
| SIZE | PATTERN | TRA | TYPE | RIM | PR | O.D. | S.W. | T.D. | Inflation | L.C.C |
| mm | mm | mm | KPa | kg | ||||||
| 500/50-17 | IMP-02 | I3 | TL | AG16.00 | 14PR | 950 | 500 | 200 | 1800 | |
| 500/50-17 | IMP-02 | I3 | TL | AG16.00 | 18PR | 950 | 500 | 480 | 4125 | |
| 400/60-22.5 | IMP-02 | I3 | TL | 1G13.00 | 18PR | 1070 | 400 | 430 | 3150 | |
| 500/45-22.5 | IMP-02 | I3 | TL | AG16.00 | 16PR | 1048 | 485 | 360 | 3075 | |
| 500/60-22.5 | IMP-02 | I3 | TL | AG16.00 | 16PR | 1170 | 500 | 320 | 3450 | |
| 500/60-22.5 | IMP-02 | I3 | TL | AG16.00 | 18PR | 1170 | 500 | 360 | 3650 | |
| 550/45-22.5 | IMP-02 | I3 | TL | AG16.00 | 16PR | 1070 | 530 | 280 | 3750 | |
| 550/45-22.5 | IMP-02 | I3 | TL | AG16.00 | 18PR | 1070 | 530 | 320 | 4000 | |
| 550/60-22.5 | IMP-02 | I3 | TL | AG16.00 | 16PR | 1238 | 550 | 280 | 3750 | |
| 550/60-22.5 | IMP-02 | I3 | TL | AG16.00 | 18PR | 1238 | 550 | 320 | 4000 | |
| 600/50-22.5 | IMP-02 | I3 | TL | AG20.00 | 16PR | 1170 | 576 | 260 | 3650 | |
| 600/50-22.5 | IMP-02 | I3 | TL | AG20.00 | 20PR | 1170 | 576 | 325 | 5150 | |
| 700/40-22.5 | IMP-02 | I3 | TL | AG24.00 | 16PR | 1180 | 710 | 220 | 3750 | |
| 700/40-22.5 | IMP-02 | I3 | TL | AG24.00 | 20PR | 1180 | 710 | 270 | ||
| 600/55-26.5 | IMP-02 | I3 | TL | AG20.00 | 16PR | 1333 | 591 | 260 | 4375 | |
| 700/50-26.5 | IMP-02 | I3 | TL | AG24.00 | 16PR | 1333 | 700 | 240 | 4750 | |
| 800/45-26.5 | IMP-02 | I3 | TL | AG28.00 | 16PR | 1333 | 800 | 220 | 5000 | |
| 800/45-26.5 | IMP-02 | I3 | TL | AG28.00 | 20PR | 1333 | 800 | 270 | ||
| 650/65-30.5 | IMP-02 | I3 | TL | AG20.00 | 16PR | 1670 | 650 | 220 | 5450 | |
| 850/50-30.5 | IMP-02 | I3 | TL | AG28.00 | 16PR | 1670 | 850 | 220 | 6700 | |
| 850/50-30.5 | IMP-02 | I3 | TL | AG28.00 | 18PR | 1670 | 850 | 250 | 8000 |
